★ High Performance Features
Efficient Hydraulic System
Twin pump flow merging hydraulic system increases efficiency. Optimized hydraulic system paired with the drive train reduces cycle time and increases productivity. Includes joystick control for precise operation.
Operator Station & Comfort
Premium operator station with superior visibility and patented MAC mounts for reduced noise. Features adjustable suspension seat, AC with fresh air circulation, and flexible single lever shifting.
Reliable Drivetrain
Countershaft transmission with upgraded components. Large rim-pull in 1st gear and higher speed in 2nd gear provide high efficiency for load and carry applications. 4WD system ensures performance in heavy-duty tasks.
Advanced Cooling & Solid Structure
Standard cooling package handles 50ºC ambient conditions. Structures undergo Finite Element Analysis (FEA) and Performance Series (PS) buckets improve loading capability.
Serviceability & Safety
System pressure test ports are standard. Big angle engine hood provides easy access. Safety design includes a 3-point touching entry, backup alarm, and compliance with all regulatory requirements.
📋 Technical Parameters
| Parameter |
Specifications |
| Bucket Capacity | 2.7-4.5 m³ |
| Rated Load Capacity | 5000 kg |
| Max. Breakout Force | 163 kN |
| Cycle Time (Total) | 10.4 s |
| Dump Height / Reach | 3089 mm / 1267 mm |
| Dimensions (L×W×H) | 8247×3068×3409 mm |
| Engine Details |
|---|
| Engine Model | WEICHAI DEUTZ |
| Rated Power | 162 kW @ 2000rpm |
| Max. Torque | 920 Nm |
| Transmission & Steering |
|---|
| Transmission Type | Fixed axle, constant engaged power shift |
| Speed Gears | 4 Forward, 4 Reverse |
| Max. Speed | 41 km/hr |
| Steering Angle | 38°±1 |
| System Capacity |
|---|
| Fuel Tank | 273 L |
| Hydraulic System | 140 L |
? Frequently Asked Questions
1 What is the rated load capacity of the SEM655D?
The SEM655D wheel loader has a rated load capacity of 5000 kg (5 tons), making it ideal for large-volume earth-moving applications.
2 What type of engine powers this wheel loader?
It is equipped with a high-configuration Weichai Deutz engine, providing a rated power of 162 kW at 2000 rpm for superior performance.
3 What are the key advantages of the hydraulic system?
The loader features a twin pump flow merging hydraulic system that increases efficiency and reduces cycle times to approximately 9.4 - 10.4 seconds.
4 Is the operator cabin designed for long working hours?
Yes, it features a premium operator station with large space, superior visibility, an adjustable suspension seat, and air conditioning with fresh air circulation.
5 What payment terms are generally accepted?
Standard payment terms include T/T (30% advance, 70% before delivery) or 100% irrevocable L/C at sight.
6 How reliable is the drivetrain for heavy-duty applications?
The SEM-designed and built axle, combined with a robust countershaft transmission and upgraded core components, ensures best-in-class reliability in harsh conditions.
