| I. BOOM SYSTEM | ||
|---|---|---|
| 1 | Maximum vertical height of boom (M) | 29.6 |
| 2 | Horizontal distribution radius of boom (M) | 25.4 |
| 3 | Depth of distribution (M) | 17.7 |
| 4 | Opening height of boom (M) | 6.7 |
| 5 | Folding type of boom | M type |
| 6 | Rotating angle of turret | 470° |
| II. HYDRAULIC & ELECTRIC SYSTEM | ||
| 1 | Type of hydraulic system | Open type |
| 2 | System working pressure (Mpa) | 31.5 |
| 3 | Hydraulic fuel tank capacity (L) | 400 |
| 4 | Working voltage (V) | 24 |
| III. PUMPING & MIXING SYSTEM | ||
| 1 | Form of concrete distribution valve | S valve |
| 2 | Hopper capacity (M³) | 0.8 |
| 3 | Rated Mixing Capacity (M³) | 8.0 |
| 4 | Mixing Drum Rotation Speed (r/min) | 0-14 |
