| Operating weight (ton) | 0.85 |
| Bucket capacity (cbm) | 0.025 |
| Engine model | KOOP KD192F-1 |
| Rated power (kw/r/min) | 7.0/3000 |
| Hydraulic pump model | China Brand |
| Max. flow (L/min) | 18 |
| Working pressure (Mpa) | 16 |
| Swing motor model | OMR200 |
| Travel motor model | SMT310 |
| Fuel tank capacity (L) | 7 |
| Hydraulic oil tank capacity (L) | 14.5 |
| Travel speed (km/h) | 1.9 |
| Swing speed (r/min) | 13 |
| Max. climbing degree (%) | 58 |
| Bucket digging force (KN) | 7.2 |
| Overall length (mm) | 2876 |
| Overall width (mm) | 840/908 |
| Overall height (to top of cab)(mm) | 1495 |
| Max. digging height (mm) | 2550 |
| Max. dumping height (mm) | 1687 |
| Max. digging reach (mm) | 3077 |
| Min. swing radius (mm) | 1483 |
